Product Summary
The Actel SX-A family of A54SX72A-CQ208B FPGAs offers a cost-effective, single-chip solution for low-power, high-performance designs. Fabricated on 0.22 μm / 0.25 μm CMOS antifuse technology and with the support of 2.5 V, 3.3 V and 5 V I/Os, the SX-A is a versatile platform to integrate designs while significantly reducing time to-market.
Parametrics
Absolute maximum ratings:(1)DC Supply Voltage for I/Os,VCCI: –0.3 to +6.0V; (2)DC Supply Voltage for Arrays, VCCA –0.3 to +3.0V; (3)Input Voltage, VI: –0.5 to +5.75V; (4)Output Voltage, VO: –0.5 to + VCCI + 0.5V; (5)Storage Temperature, TSTG: –65 to +150°C.
Features
Features: (1)Hot-Swap Compliant I/Os; (2)Power-Up/Down Friendly (No Sequencing Required for Supply Voltages); (3)66 MHz PCI Compliant; (4)Nonvolatile, Single-Chip Solution; (5)Configurable I/O Support for 3.3 V / 5 V PCI, 5 V TTL, 3.3 V LVTTL, 2.5 V LVCMOS2; (6)2.5 V, 3.3 V, and 5 V Mixed-Voltage Operation with 5 V Input Tolerance and 5 V Drive Strength; (7)Devices Support Multiple Temperature Grades; (8)Configurable Weak-Resistor Pull-Up or Pull-Down for I/O at Power-Up; (9)Individual Output Slew Rate Control; (10)Up to 100% Resource Utilization and 100% Pin Locking; (11)Deterministic, User-Controllable Timing; (12)Unique In-System Diagnostic and Verification Capability with Silicon Explorer II; (13)Boundary-Scan Testing in Compliance with IEEE Standard 1149.1 (JTAG); (14)Actel Secure Programming Technology with FuseLoc Prevents Reverse Engineering and Design Theft.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 A54SX72A-CQ208B |
|
IC FPGA SX-A 108K 208-CQFP |
Data Sheet |
|
|
||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||
|
A54SX08 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
|
A54SX08-1FG144 |
|
IC FPGA SX 12K GATES 144-FBGA |
Data Sheet |
|
|
||||||
|
A54SX08-1FG144I |
|
IC FPGA SX 12K GATES 144-FBGA |
Data Sheet |
|
|
||||||
|
A54SX08-1FGG144 |
|
IC FPGA SX 12K GATES 144-FBGA |
Data Sheet |
|
|
||||||
|
A54SX08-1FGG144I |
|
IC FPGA SX 12K GATES 144-FBGA |
Data Sheet |
|
|
||||||
|
A54SX08-1PL84 |
|
IC FPGA SX 12K GATES 84-PLCC |
Data Sheet |
|
|
||||||
